Parts List
ITEM PART NUMBER DESCRIPTION
1 N010-1008-SER PRO285-LID ASSY x
2 Z305-0012 NGZ GRID, COOKING CAST LEFT (285) x
3 Z305-0013 NGZ GRID, COOKING CAST RIGHT (285) x
4 N325-0083 NGZ, HANDLE LID (PRO285) x
5 N370-0861-SER KIT, BRACKET FRONT/REAR ELEMENT x
6 Z585-0015 NGZ, BASE LINER, PORCELAIN COATING (PRO285E) x
7 Z010-0048 NGZ, ELEMENT (PRO285E) x
8 Z135-0003 NGZ, CASTING BASE BLACK (PRO285E) x
9 Z690-0001 NGZ, THERMOSTAT ASSY (PRO285E) x
10 N010-1009-SER ASSY, CRADDLE (PR0285E) x
11 N710-0079 NGZ, PAN DRIP (285/285X) x
12 N010-0830 ASSY,DRIP PAN PLATE (PRO285) x
13 N135-0048 CASTING, LID PRO285 x
14 N685-0017 TEMP GAUGE, PRO285 x
15 Z585-0014 NGZ, LID HEAT SHIELD (PRO285E) x
16 N010-1010-SER ASSY, LID HANDLE (PRO285E) x
17 N485-0023 NGZ PIN, CLEVIS 6MM X16MM (PRO285) x
18 N485-0021 NGZ PIN, HAIRPIN COTTER 2MM X 28MM (285) x
19 N655-0179 NGZ, SUPPORT, LID HANDLE LEFT x
20 N655-0180 NGZ, SUPPORT, LID HANDLE RIGHT x
21 Z570-0029 SCREW, 10-24 35 MM STN STL PAN HEAD x
22 Z735-0009 NGZ,WASHER, LOCK-SPLIT STN STL M5 x
PRO285-STAND OPTIONAL CART AND SHELVES FOR PRO285 ac
