EN
FR
PG.21
PG.41
www.napoleongrills.com
N415-0539 NOV 22.18
WARNING
Do not try to light this appliance without
reading the “LIGHTING” instrucons secon
of this manual.
Do not store or use gasoline or other
ammable liquids or vapors in the vicinity of
this or any other appliance. An L.P. cylinder
not connected for use must not be stored in
the vicinity of this or any other appliance.
If the informaon in these instrucons is
not followed exactly, a re or explosion may
result, causing property damage, personal
injury or death.
DANGER
IF YOU SMELL GAS:
•
Shut o gas to the appliance.
• Exnguish any open ame.
• Open lid.
• If odor connues, keep away from the
appliance and immediately call your gas
supplier or re department.
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
PRO500-3
This gas grill must be used only outdoors in a well-venlated space and must not be used inside a building,
garage, screened-in porch, gazebo or any other enclosed area.
DO NOT DISCARD
Noce to Installer: Leave these instrucons with the grill owner for future reference.
Adults and especially children should be alerted to the hazards of high surface temperatures.
Young children should be supervised near the gas grill.
Wolf Steel Ltd.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
grills@napoleonproducts.com
!
!

Table of Contents

Questions and Answers

  • A
    Alexander PetersonAug 22, 2025
    Why won't my Napoleon PRO500-3 rear and side burners light with the igniter?
    • R
      Robert MillerAug 22, 2025
      If the rear and side burners on your Napoleon Grill will not light with the igniter but will light with a match, it could be due to a dead or incorrectly installed battery, a loose electrode wire or switch terminal wires, or lifting flames on the burner. Replace the battery with a premium heavy-duty battery. Check that the electrode wire is firmly pushed onto the terminal on the back of the igniter and that the lead wires from the module to the ignition switch (if equipped) are firmly pushed onto their respective terminals. Slightly close the air shutter.
  • K
    kelly21Sep 18, 2025
    Why won't the main burner on my Napoleon PRO500-3 Grill light with the igniter, but will light with a match?
    • B
      Brandon StevensSep 18, 2025
      If the main burner on your Napoleon Grill will not light with the igniter but will light with a match, the jet-fire outlet may be dirty or clogged. Clean the jet-fire outlet with a soft bristle brush.
  • R
    Rodney YoungSep 16, 2025
    Why won't the rear and side burners on my Napoleon PRO500-3 Grill light with the igniter?
    • B
      Brian JohnsonSep 16, 2025
      If the rear and side burners on your Napoleon Grill won't light with the igniter but will light with a match, it could be due to a dead or incorrectly installed battery, a loose electrode wire or switch terminal wires, or lifting flames on the burner. Replace the battery with a premium heavy-duty battery. Check that the electrode wire is firmly pushed onto the terminal on the back of the igniter. Also, check that the lead wires from the module to the ignition switch (if equipped) are firmly pushed onto their respective terminals. Close the air shutter slightly (see previous problem).
  • T
    Tracy SchultzSep 14, 2025
    Why do my Napoleon Grill burners have a yellow flame and smell of gas?
    • E
      elizabeth23Sep 14, 2025
      A yellow flame and the smell of gas from your Napoleon Grill burners could be due to a spider web or other debris, or an improper air shutter adjustment. Thoroughly clean the burner by removing it. Open the air shutter slightly according to the combustion air adjustment instructions. Note: This adjustment must be done by a qualified gas installer.
  • T
    tinamooreSep 12, 2025
    What to do if my Napoleon Grill burner output is too low on the 'high' setting?
    • K
      Kayla CruzSep 13, 2025
      If your Napoleon Grill's burner output is too low on the 'high' setting, with a rumbling noise and fluttering blue flame, it could be due to several factors: lack of gas, a pinched supply hose, a dirty or clogged orifice, spider webs or other material in the venturi tube, or the propane regulator being in a 'low flow' state. Check the gas level in the propane cylinder and reposition the supply hose if necessary. Clean the burner orifice and venturi tube. Ensure the lighting procedure is followed carefully: all gas grill valves must be in the off position when the tank valve is turned on, and turn the tank on slowly to allow pressure to equalize.
  • M
    Mallory MendozaSep 12, 2025
    How to fix low heat or low flame on my Napoleon PRO500-3 Grill when the valve is on high?
    • M
      Michael PetersonSep 12, 2025
      The issue of low heat or low flame on your Napoleon Grill might arise from a few reasons. For propane grills, it could be due to an incorrect lighting procedure. For natural gas grills, the supply line might be undersized. For both types, improper preheating could be the cause. Ensure you follow the lighting procedure carefully, keeping all gas grill valves in the off position when turning on the tank valve. Turn the tank on slowly to allow pressure to equalize. The pipe must be sized according to the installation code. Preheat the grill with both main burners on high for 10 to 15 minutes.
  • G
    grahamlisaSep 9, 2025
    What to do if the burners on my Napoleon Grill will not cross light each other?
    • T
      Teresa DavisSep 9, 2025
      If the burners on your Napoleon Grill will not cross light each other, the cross light brackets may be dirty or corroded. Clean or replace them as required.
  • M
    Michael LynchSep 7, 2025
    Why doesn't the side/rear burner ignition work on my Napoleon PRO500-3?
    • A
      April ReynoldsSep 7, 2025
      If the illumination of the knob and switch lights work fine, but the side/rear burner ignition does not work on your Napoleon Grill, the ignitor switch or the ignitor block may not be working properly. Replace the ignitor switch if the switch light illuminates when you turn the light switch on. Check the switch connection inside the control panel. If there’s no light on the switch when you turn it on, replace the ignitor block if the switch illuminates and sparking noise can be heard.
  • M
    mckeematthewSep 5, 2025
    Why don't the knob lights illuminate on my Napoleon PRO500-3 Grill?
    • R
      rmendozaSep 5, 2025
      If the ignitor, oven, and cabinet lights on your Napoleon Grill work, but the knob lights don’t illuminate when turning the power switch ON, the motion sensor detector or the wire harness may not be working properly. Ensure the blue indicator is ON. Turn the sensor ON by clicking the motion detector button. If the blue indicator is ON, replace the motion sensor. Replace the wire harness of the control panel.
  • J
    James MillerSep 4, 2025
    Why are the flames lifting away from the burner on my Napoleon PRO500-3 Grill?
    • C
      Craig LivingstonSep 4, 2025
      If flames lift away from the burner of your Napoleon Grill, accompanied by the smell of gas, and possibly difficulties in lighting, it may be due to improper air shutter adjustment. Close the air shutter slightly according to combustion air adjustment instructions. (This must be done by a qualified gas installer.)

Summary

Napoleon Presidents Limited Lifetime Warranty

Safe Operating Practices

Propane Cylinder Specifications

Gas Hook-Up Instructions

Cylinder Connection

Natural Gas Hook-Up

Electrical Precautions

Leak Testing Instructions

Lighting Instructions

Main Burner Lighting

Step-by-step guide for lighting the main burners, including pilot ignition.

Cooking Instructions

Initial Lighting

First-time use guidance, including initial odor and how to burn-in the grill.

Main Burner Use

Infrared Main Burner Use (If Equipped)

Infrared Side Burner Use (If Equipped)

Protection Of Your Infrared Burners

Cleaning Instructions

Maintenance Instructions

Combustion Air Adjustment

Details on adjusting the air shutter for optimal burner flame quality and performance.

Adjusting the air shutter

WARNING! When reinstalling the burner...

Protection Of Infrared Burners

WARNING! Always wear protective gloves...

Lights

Troubleshooting

Ordering Replacement Parts

Napoleon PRO500-3 Specifications

General IconGeneral
TypeGas Grill
Burners3
Total Cooking Area500 sq. in.
MaterialStainless Steel
Side BurnerYes
Rotisserie KitOptional
BTU48, 000
Fuel TypePropane or Natural Gas
IgnitionElectronic
Ignition SystemElectronic
BTU Output48, 000 BTU
WarrantyPresident’s Limited Lifetime Warranty
