National Instruments 636 Series

© National Instruments | 7-43
X Series User Manual
CTR 2 A 11 (PFI 0)
CTR 2 Z 10 (PFI 1)
CTR 2 B 43 (PFI 2)
CTR 3 SRC 6 (PFI 5)
CTR 3 GATE 5 (PFI 6)
CTR 3 AUX 38 (PFI 7)
CTR 3 OUT 39 (PFI 15)
CTR 3 A 6 (PFI 5)
CTR 3 Z 5 (PFI 6)
CTR 3 B 38 (PFI 7)
FREQ OUT 1 (PFI 14)
Table 7-10. X Series USB Screw Terminal Device Default
NI-DAQmx Counter/Timer Pins
Counter/Timer Signal Default Pin Number (Name)
CTR 0 SRC 81 (PFI 8)
CTR 0 GATE 83 (PFI 9)
CTR 0 AUX 85 (PFI 10)
CTR 0 OUT 89 (PFI 12)
CTR 0 A 81 (PFI 8)
CTR 0 Z 83 (PFI 9)
CTR 0 B 85 (PFI 10)
CTR 1 SRC 76 (PFI 3)
CTR 1 GATE 77 (PFI 4)
CTR 1 AUX 87 (PFI 11)
CTR 1 OUT 91 (PFI 13)
Table 7-9. X Series PCI Express/PXI Express/USB Mass Termination/USB BNC Device
Default NI-DAQmx Counter/Timer Pins (Continued)
Counter/Timer Signal Default Connector 0 Pin Number (Name)
