National Instruments 776570-00 Getting Started

Chapter 3 Configuring Your SCXI Hardware and Software
Getting Started with SCXI 3-20 www.ni.com
Table 3-13. SCXI-1121 Excitation Level Jumper Configuration
Jumpers
Excitation
Channel
3.333 V or 0.150 mA
(Factory-Default Position)
10 V or 0.450 mA
0
1
2
3
W16 W26
123
W16
1
2
3
W26
123
W16
1
2
3
W26
W24 W25
123
W24
123
W25
123
W24
123
W25
W36 W37
123
W36
123
W37
123
W36
123
W37
W48 W49
123
W48
123
W49
123
W48
123
W49
