GPIB Hardware Installation Guide and Specifications | © National Instruments | 23
Power Requirements
USB bus-powered device
+5 V (VBUS) 80 mA, Typical
500 mA, Maximum
Physical Characteristics
Dimensions 8.0 cm × 6.1 cm × 2.0 cm
(3.2 in. × 2.4 in. × 0.8 in.)
Weight 153 g (5.4 oz), includes USB cable weight
Connector
GPIB IEEE 488 24-pin connector
USB USB standard Type A plug
Jackscrew
Thread M3.5 × 0.6
Torque 0.56 N · m (5.0 lb · in.), maximum
Environment
Operating ambient temperature 0 °C to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Operating relative humidity 10% to 90%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Storage ambient temperature -20 °C to 70 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Storage relative humidity 5% to 95%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
PCI-8232
Performance
GPIB
3-wire up to 1830 kbytes/s
HS488 up to 7920 kbytes/s
