26 | ni.com | GPIB Hardware Installation Guide and Specifications
PCI-GPIB
Performance
GPIB
3-wire up to 1536 kbytes/s
HS488 up to 7885 kbytes/s
Power Requirements
PCI-GPIB/TNT4882C
1
+3.3 V 121 mA, Typical
182 mA, Maximum
+5 V 300 mA, Typical
450 mA, Maximum
PCI-GPIB/TNT5004
2
+5 V 150 mA, Maximum
VIO 5 mA, Maximum
PCI-GPIB/LP (Low Profile)
3
+5 V 300 mA, Typical
450 mA, Maximum
Physical Characteristics
Dimensions
PCI-GPIB/TNT4882C 13.3 cm × 10.7 cm (5.25 in. × 4.20 in.)
PCI-GPIB/TNT5004 12 cm × 6.44 cm (4.72 in. × 2.54 in.)
PCI-GPIB/LP 12 cm × 6.44 cm (4.87 in. × 2.54 in.)
1
PCI-GPIB boards manufactured before 2003 use the TNT4882C controller. The assembly number printed
on these boards is 183617x-01.
2
A later revision of PCI-GPIB boards uses the TNT5004 controller. The assembly number printed on these
boards is 188513x-01.
3
PCI-GPIB/LP is a low profile PCI-GPIB board designed to fit in low-profile machines. It uses a special
cable to convert between the micro-DSub connector of the board and the GPIB connector.
