GPIB Hardware Installation Guide and Specifications | © National Instruments | 25
PCIe-GPIB and PCIe-GPIB+
Performance
GPIB
3-wire up to 1670 kbytes/s
HS488 up to 7980 kbytes/s
Power Requirements
1
PCIe-GPIB (+3.3 V) 320 mA, Typical
500 mA, Maximum
PCIe-GPIB+ (+3.3 V) 360 mA, Typical
560 mA, Maximum
Physical Characteristics
1
Dimensions 9.754 cm × 6.888 cm (3.840 in. × 2.712 in.)
Connector
GPIB IEEE 488 24-pin connector
PCIe x1
Environment
1
Operating ambient temperature 0 °C to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Operating relative humidity 10% to 90%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Storage ambient temperature -20 °C to 70 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Storage relative humidity 5% to 95%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
1
A version of the PCIe-GPIB controller (part number 190243x-01, manufactured prior to 2008) differs from
these specifications in power consumption, physical dimensions, and ambient temperature range. For
specific details, refer to the Notice of Board Change—PCIe-GPIB on ni.com.
