© National Instruments | 4-7
NI 6612 User Manual
PFI 16 / P0.16 24
PFI 17 / P0.17
PFI 18 / P0.18 59
PFI 19 / P0.19
PFI 20 / P0.20 27
PFI 21 / P0.21
PFI 22 / P0.22 62
PFI 23 / P0.23
PFI 24 / P0.24 30
PFI 25 / P0.25
PFI 26 / P0.26 65
PFI 27 / P0.27
PFI 28 / P0.28 33
PFI 29 / P0.29
PFI 30 / P0.30 68
PFI 31 / P0.31
PFI 32 / P1.0 42
PFI 33 / P1.1 39
PFI 34 / P1.2 42
PFI 35 / P1.3 41
PFI 36 / P1.4 39
PFI 37 / P1.5 41
PFI 38 / P1.6 36
PFI 39 / P1.7
Table 4-2. Signals and D GND Pin Number on
68-Pin Screw Terminal Accessory (Continued)
PFI/DIO Number Pin Number for D GND
