© National Instruments | 4-3
NI 651x User Manual
Figure 4-2. NI 6511 Input Signal Connection Example
Figure 4-3. NI 6514/6515 Input Signal Connection Example
Figure 4-4. NI 6518/6519 Input Signal Connection Example
+3.3 V
P<0..7>.<0..7>
P<0..7>.COM
NI 6511
0 V ~ +30 V
or
0 V ~ 30 V
AC Input
Photocoupler
AC Input
Photocoupler
+3.3 V
P<0..3>.<0..7>
P<0..3>.COM
NI 6514/15
0 V ~ +30 V
or
0 V ~ –30 V
AC Inp
ut
Photocoupler
+
3.3 V
P<0..1>.<0..7>
IN.COM
NI 6518/19
0 V ~ +30 V
or
0 V ~ –30 V
