16 | ni.com | NI Digital Waveform Generator/Analyzer Getting Started Guide
NI also offers the NI SMB-2163 breakout box for National Instruments single-ended digital
waveform generator/analyzers. The NI SMB-2163 offers coaxial SMB connectors for each
channel on the DDC connector, providing an easy way to connect to other devices for testing and
debugging. For more information about the NI SMB-2163, refer to the NI SMB-2163 User
Guide.
Figures 7 and 8 show how to connect a single-ended NI digital waveform generator/analyzer
and the NI CB-2162 and NI SMB-2163, respectively, using the NI SHC68-C68-D4 cable.
Figure 7. Connecting the NI CB-2162 Accessory
Figure 8. Connecting the NI SMB-2163 Accessory
1 PXI Chassis with NI Digital Waveform
Generator/Analyzer
2 NI SHC68-C68-D4 Cable
3 NI CB-2162 Accessory
1 PXI Chassis with NI Digital Waveform
Generator/Analyzer
2 NI SMB-2163 Accessory
3 NI SHC68-C68-D4 Cable
NI PXI-6551
50 MHz Digital I/O
DIGITAL DATA & CONTROL
PFI 0
ACCESS ACTIVE
CLK
IN
CLK
OUT
NI PXI-1042
1
3
2
J15
J5
J6
NI PXI-6551
50 MHz Digital I/O
DIGITAL DATA & CONTROL
PFI 0
ACCESS ACTIVE
CLK
IN
CLK
OUT
NI PXI-1042
2
3
1
