© National Instruments Corporation 7 NI USB-6008/6009 User Guide and Specifications
Features
The NI USB-6008/6009 features a USB connector, USB cable strain relief, two screw terminal
connector plugs for I/O, and an LED indicator, as shown in Figure 4.
Figure 4. NI USB-6008/6009 Top and Back Views
USB Connector and USB Cable Strain Relief
The NI USB-6008/6009 features a USB connector for full-speed USB interface. You can provide strain
relief for the USB cable by threading a zip tie through the USB cable strain relief ring and tightening
around a looped USB cable, as shown in Figure 5.
Figure 5. NI USB-6008/6009 Strain Relief
1USB Cable Strain Relief
2 Screw Terminal Connector Plug
3 LED Indicator
4USB Connector
NI USB-6009
8 Inputs, 14-bit, Multifunction I/O
32 Digital 17
1 Analog 16
1
2 2 4
3
1
