Chassis Fan Replacement Guide 4 ni.com
4. Disconnect the fan cable from the inline connector. The connector is
shown in Figure 2.
Figure 2. Fan Cable Inline Connector
1Fan 2 Fan Cable Inline Connector
2
1
