Table 2. PXIe-5413 ACCESS LED Indicators
LED Color Indication
6 No color (off) The PXIe-5413 is not yet functional.
Amber The PXIe-5413 is being accessed.
Green The PXIe-5413 is ready to be programmed by NI-FGEN.
The ACTIVE LED indicates the PXIe-5413 hardware state.
Table 3. PXIe-5413 ACTIVE LED Indicators
LED Color Indication
7 No color (off) The PXIe-5413 is not generating.
Amber The PXIe-5413 is armed and waiting for a trigger.
Green The PXIe-5413 has received a trigger and is generating a waveform.
Red The PXIe-5413 has detected an error. NI-FGEN must access the
PXIe-5413 to determine the cause of the error. The LED remains red until
the error condition is removed. Example errors include the following:
• Phase-locked loop (PLL) unlocked: The PXIe-5413 has detected an
unlocked condition on a previously locked PLL. A PLL that is
unlocked while in reset does not show an error.
• The PXIe-5413 has powered down because the internal temperature
exceeded the maximum limit. The over-temperature condition must
be corrected and the hardware reset. To reset the hardware, call
niFgen Reset Device or niFgen_ResetDevice.
1
AUX 0 Connector
Note The AUX 0 connector accepts a standard, third-party HDMI
™
type C cable,
but the AUX 0 port is not an HDMI interface and the specified performance of the
AUX 0 connector is not guaranteed if a third-party HDMI cable is used. Use NI
cable assembly SHH19-MH19-AUX for all AUX 0 connections. Do not connect the
AUX 0 port on the PXIe-5413 to the HDMI port of another device. NI is not liable
for any damage resulting from such signal connections.
Refer to the following figure and table for information about the PXIe-5413 AUX 0 connector
pins.
1
For more information about keeping the PXIe-5413 within internal temperature limits, refer to the
Maintain Forced-Air Cooling Note to Users included with your PXIe-5413 and at ni.com.
8 | ni.com | PXIe-5413 Getting Started Guide
