RMC-8356 Installation Guide | © National Instruments | 15
Exterior Cleaning
Caution Avoid getting moisture inside the chassis during exterior cleaning,
especially through the top vents.
Do not wash the front- or rear-panel connectors or switches. Cover these components
while cleaning the chassis.
Do not use harsh chemical cleaning agents; they may damage the chassis. Avoid
chemicals that contain benzene, toluene, xylene, acetone, or similar solvents.
Clean the exterior surfaces of the chassis with a dry lint-free cloth or a soft-bristle brush. Do not
use abrasive compounds on any part of the chassis.
Specifications
This section lists the RMC-8356 electrical, mechanical, and environmental specifications.
Electrical
AC Input
Input voltage range ........................................... 100 VAC to 240 VAC
Operating voltage range.................................... 90 VAC to 264 VAC
Input frequency................................................. 50 Hz/60 Hz
Operating frequency range ............................... 47 Hz to 63 Hz
Input current rating ........................................... 4.2 A max
Power disconnect
............................................... The AC power cable provides main power
disconnect. Depressing the front panel power
switch enables or inhibits the internal power
supply.
Caution Using the RMC-8356 in a manner not described in this document may
impair the protection the RMC-8356 provides.
Mainboard
Socket ............................................................... LGA 1151
Chipset .............................................................. Intel C236 chipset
Memory slots .................................................... 4 x Dual Channel DDR4 UDIMM,
unbuffered ECC/Non-ECC
PCI Express ...................................................... 1 x PCI Express 3.0 x16 slot
SATA................................................................. 4 x 3.5 in. Hot-Swappable SATA3 Bays
