RMC-8356 Installation Guide | © National Instruments | 7
• Reset Button—Reboots the system.
• Power Button—Removes the main power but maintains standby power. To perform many
maintenance tasks, you must also unplug system before servicing.
Upgrade/Optional Equipment
Memory Upgrades
National Instruments has tested and verified that the DDR-4 UDIMMs we offer work with the
RMC-8356. We recommend you purchase your DDR-4 UDIMM modules from National
Instruments. Other off-the-shelf DDR-4 UDIMM modules are not guaranteed to work properly.
Upgrade Options
Table 2 lists upgrade options available for the RMC-8356.
RMC-8356 Overview
The RMC-8356 is a 1U PC-based controller for remote control of PXI chassis.
The controller provides leading-edge processing power with Intel Xeon E3-1275-V5
processors, high disk bandwidth with RAID support, high I/O bandwidth with a
PCI Express 3.0 x16, dedicated Intel Graphics w/ DP, and up to 64 GB of UDIMM Non-ECC
memory.
Safety Information
Caution Before undertaking any troubleshooting, maintenance, or exploratory
procedure, carefully read the following caution notices.
Caution To prevent damage, you must employ industry-standard ESD prevention
measures during installation, maintenance, and operation.
Caution Overloading the circuits may damage supply wiring. Do not exceed the
ratings on the equipment nameplate when connecting equipment to the supply circuit.
Caution There is a danger of explosion if the onboard battery is installed upside
down (which reverses its polarities). This battery must be replaced only with the same
or an equivalent type recommended by the manufacturer (CR2032).
Table 2. RMC-8356 Upgrade Options
Orderable P/N Description
785651-01 Spare 1 TB HDD
785652-01 Spare 16 GB DDR4 memory module
