4 | ni.com | RMC-8356 Installation Guide
Memory
• 16 GB UDIMM Non-ECC DDR4 memory standard (1 ×16 GB)
• Maximum memory supported: 64 GB Unregistered Non-ECC DDR4-2133 MHz in
4 DIMM sockets.
Slots
• 1 x PCI Express 3.0 x16 slot
Video
• Aspeed AST2400 BMC (max resolution 1280 × 1024)
Note Disabled by default.
• Intel HD P530 Graphics, 2 × Display Port, 1 × DVI
HDD
• 1 x 1 TB SATA3 hard drive JBOD
Onboard LAN
• 1 x Intel PHY i219LM Gigabit Ethernet controller
• 1 x Intel I210-AT
Onboard I/O
• 1 x Front Serial port
• 1 x VGA port
Note Disabled by default.
• 2 x Display Port
• 1 x DVI
• 2 x USB 2.0 ports (rear)
• 2 x USB 3.0 ports (rear)
• 2 x USB 3.0 ports (front)
• 2 x RJ-45 ports
Power Supply
• 350 W AC power supply w/ PFC
Fan
• Internal 4 x 4 cm Fans
