natus neoBLUE mini - Service Manual

Questions and Answers

T
Tara MccannAug 1, 2025
What to do if the natus neoBLUE mini light does not appear when turned on?
- A
  agreeneAug 1, 2025
  If the light on your Natus Medical Equipment doesn't turn on, several issues could be the cause. First, ensure the AC outlet is working and the power switch is in the ON position. Check that the power cord is fully plugged into the device socket, and try a different power cord if necessary. If these steps don't work, the power cable or Current PCB might be damaged. Check the voltage at the end of the power cable (should be 12 ± 5%) and at specific points on the Current PCB (JP1). If the voltage is incorrect, consider replacing the power supply or the Current PCB. A damaged LED PCB may also be the reason, so replacing it might solve the problem.
K
Kevin WoodAug 5, 2025
What to do if the light intensity of my natus Medical Equipment will not adjust?
- J
  James WeaverAug 5, 2025
  If the light intensity on your Natus Medical Equipment won't adjust, the Current PCB might be damaged, or the Current PCB and LED PCB might not be connected properly. Try replacing the Current PCB and check the alignment of the JP1 and JP2 connectors. If the maximum adjustment limit has been reached, consider replacing the LED PCB.
V
Valerie WilsonAug 10, 2025
What to do if multiple LED strings go out on my natus neoBLUE mini Medical Equipment and I cannot attain appropriate intensity?
- J
  Jonathan HunterAug 10, 2025
  If multiple LED strings go out on your Natus Medical Equipment and you can't get the right intensity, it could be a damaged LED light panel or the maximum adjustment limit has been reached. Replace the LED light panel to resolve this issue.
J
Jill GonzalezAug 14, 2025
Why is the lens of my natus Medical Equipment excessively hot?
- D
  Dr. Antonio MillerAug 14, 2025
  If the lens on your Natus Medical Equipment is getting too hot (above 50°C/122°F), it might be due to blocked air vents. Make sure the vents are clear. If the vents are clear, the main enclosure fan may not be running correctly. In this case, consider replacing the Current PCB.
R
Randy JensenAug 18, 2025
How to fix natus Medical Equipment light that does not hold its position?
- G
  Gwendolyn SwansonAug 18, 2025
  If the light on your Natus Medical Equipment isn't holding its position, check the arm bolts and tighten or loosen them as needed. If the light drifts, the gooseneck might have a memory preventing it from holding certain positions; try repositioning it or using the arm to achieve the desired location, ideally with the arm parallel to the light height.
R
Robert ClarkAug 22, 2025
What to do if the enclosure of my natus neoBLUE mini Medical Equipment bubbles or starts to deform?
- C
  castillodannyAug 22, 2025
  If the enclosure of your Natus Medical Equipment starts to bubble or deform, it's likely because the light is too close to a radiant heat source. Reposition the light to the side of the radiant warmer, no farther than 12 inches (30.5 cm) from the infant.
J
Jason KingAug 27, 2025
What to do if LED string(s) goes out on my natus neoBLUE mini Medical Equipment?
- C
  Carla FordAug 27, 2025
  If an LED string goes out on your Natus Medical Equipment, it could be due to an LED short or open. If the device still produces enough light, increasing the intensity may be enough, and there's no need to replace the panel. However, if the device doesn't produce enough light, you should replace the LED light panel.

Summary

Product Description

Intended Use

Specifies the intended purpose of the neoBLUE mini LED Phototherapy System for treating neonatal hyperbilirubinemia.

Physical Characteristics

Details the device's mobile nature, LED technology, enclosure, arm design, light output, and expected lifespan.

Power Requirements and Accessories

Describes the device's 12V DC power supply operation and mains power connection.

Safety Symbols

General Safety Symbols and Meanings

Details various safety symbols used on the device and their corresponding meanings for user safety.

Routine Maintenance Procedures

Cleaning Procedures

Details methods for cleaning the exterior of the light enclosure and adjustable arm.

Safety Testing

Explains the safety tests performed according to IEC and UL standards.

Performance Verification

Covers procedures for verifying the device's general performance and light intensity.

Troubleshooting the neoBLUE mini light

Troubleshooting Common Issues

Provides a guide to diagnose and resolve common problems with the neoBLUE mini device.

Repair Procedures

Light Component Removal

Procedures for removing key components like the lens, LED PCB, and Current PCB from the device.

Arm and Mount Disassembly

Steps to detach the light enclosure from the arm and remove the pole mount.

Device Timer Information

Details on the built-in device timer, its function, and limitations.

Spare Parts List

An itemized list of available spare parts with part numbers and descriptions.

Measuring Light Intensity with a Radiometer

Radiometer Measurement and Calibration

Information on using radiometers to check light intensity, including calibration and conversion charts.

natus neoBLUE mini Specifications

General

Device Type	Phototherapy System
Model	neoBLUE mini
Manufacturer	Natus Medical Incorporated
Light Source	LED
Irradiance Level	Adjustable
Input Voltage	100-240 VAC, 50/60 Hz
Irradiance (typical)	≥30 µW/cm²/nm
Power Source	AC Power
Features	Portable
Safety Features	Automatic shut-off
Spectral Output	Narrow-band blue light
