NV30/NV40 Operations and Maintenance Manual Operating the transmitter
Issue 3.3 2014-12-10 Page 2-3
Information is displayed in a series of pages (screens) that serve specific transmitter functions. The
AUI has the following configurable displays:
• Login Page (see Logging into the AUI on page 2-3)
• Events logs (see Logs page - viewing transmitter log on page 2-16)
• Instrumentation panels (Viewing instrument panels on page 2-27)
• Real-time meters (see Meters Page on page 2-40)
• Presets (see Presets - editing operational settings on page 2-44)
• Transmitter status (see Viewing transmitter status on page 2-59)
• Factory settings (see Factory Settings on page 2-61)
• System settings (see System Settings on page 2-70)
• User accounts (see User accounts on page 2-79)
• Changeover (see Changeover page on page 2-83)
• User settings (see User settings on page 2-84)
• Remote input/output configuration (see Remote I/O page on page 2-104)
See the complete AUI flow diagram illustrated in Figure 2.2 on page 2-5.
Logging into the AUI
The transmitter’s AUI provides a means to restrict local and remote access to transmitter control
functions to authorized users only. Users can create accounts that can be pre-defined to set access
restriction from view-only (no control), full control (all permissions), custom (select permissions) and
administrative control.
Remote access
To access the transmitter’s AUI remotely, perform the following steps:
1. Configure your network settings (see Setting up the network on page 2-85).
