NV30/NV40 Operations and Maintenance Manual Operating the transmitter
Page 2-4 Issue 3.3 2014-12-10
2. On your router or firewall software, open ports 3501 (3501 is factory default, use corresponding
other port if changed) and 80 and close (restrict access to) all other ports. If you are using RDS
data, open port 7005. If you are using SNMP, open ports 161 (Agent) or 162 (Traps).
3. When properly configured as noted above, the login menu (see Figure 2.3 on page 2-9) will
appear in your web browser when IP address is accessed. Your IP address and any login
messages appear in a box at the top, beside the logo, and the current AUI software version
number appears along the bottom of the login window.
4. Log in to the AUI by entering the appropriate parameters in the login window.
• In the Language field, press the down-arrow to review a drop-down menu displaying the
available language options, and select one.
• In the User field, enter the username. Default is “Nautel”.
• In the Password field, enter the password. Default is blank.
• Press Submit to accept your login parameters and display the AUI home page (Figure 2.6 on
page 2-14). Note: The opening screen (the Home page) will have the layout from the previ-
ous login session.
Note:
The Nautel AUI is factory configured with a default login username and password. Nautel
recommends that you change the password to improve overall system security. See Changing the
password on page 2-81.
Note:
If you do not have a user account, it must be set up by an existing user with proper permissions.
See Adding an account on page 2-80.
Note:
If no login attempt is made after 60 seconds, a timeout feature will be activated and the web
browser will be need to be refreshed in order to attempt another login.
