Nautilus E618 Service Manual

103
3. Remove the Pedal.
4.Usinga6mmhexwrench,removetheindicatedhardwarefromthe
Crank Arm and Leg.
5. Remove the old Leg and replace with the new one.
6. Installation is the reverse procedure.
7. Discard the old parts.
8. Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully assembled
and inspected for correct performance in accordance
with the Owner’s Manual.
Leg
Crank Arm

Nautilus E618 Specifications

General

Display	LCD
Programs	29
Heart Rate Monitoring	Contact and telemetry enabled
Bluetooth Connectivity	Yes
User Profiles	4
Maximum User Weight	300 lbs
