Nautilus F3AT - Step 4: Install Guide Rods and Bumpers

14
Step 4: Install Guide Rods and Bumpers
Locate the following for this step:
Parts:
• Ref 3, Guide Rod Qty. 2
• Ref 11, Bumper Guide Rod Qty. 2
Hardware:
• None
Tools:
• None
Refer to Figure 5:
4-1 Place the Guide Rods and Bumpers in the Bottom
Triangle Weldment, allowing the Rods to lean
forward.
Figure 5:
ASSEMBLY GUIDE
