NB 3000 EXERCISE BIKE
ASSEMBLY INSTRUCTIONS
STEP 6: Installing Seat
Secure the seat (#5) onto the seat post (#3) by tightening the hex nut below the
seat frame. Then loosen the pull knob (#14) and install the seat post into the frame
(#1). You will want to adjust seat (#5) to desired angle after you test for comfort.
STEP 7: Installing Pedals & Straps
Attach the pedals (#10-1[L] and #10-1[R]) to crank (#4) using supplied wrench. The
left pedal is left-handed thread, and must be tightened counter-clockwise. The
right pedal is right-handed thread, and must be tightened clockwise. After pedals
are installed, attach pedal straps to pedals at desired length.
