Navien NaviLink User Manual

40
Appendix
Specifications
Wi-Fi
Specification 2.4 GHz, IEEE Std. 802.11b/g/n (20 MHz)
Frequency range 2,412 MHz–2,462MHz for 802.11b/g/n (20 MHz)
Channel 11 channels for 802.11b/g/n (20 MHz)
Channel spacing 5 MHz
Modulation type
802.11b: DSSS/CCK
802.11g/n: OFDM
Max. RF output
power
18.88dBm for 802.11b
20.69dBm for 802.11g
20.32dBm for 802.11n (HT20)
Adjustable output power but follow the
802.11b/g/n standard
Security WEP, WPA/WPA2, WPA2-PSK/WPA-PSK
Ethernet
Specification 10/100M Base-TX wired LAN
Protocols TPC/IPv4, DHCP
Standards
Fully complies with IEEE 802.3/IEEE 802.3u,
ANSI X3T12 TP-PMD 1995 standards
General
Ports
1 - 10/100M Auto-Negotiation Ethernet RJ45
port supporting Auto MDI/MDIX
3 - RS-485 communication RJ45 ports
Cables
10BASE-TX: UPT category 3, 4, 5 cable
(maximum 100 m)
EIA/TIA-568 100Ω STP
(maximum 100 m)
100BASE-
TX: UPT category 5, 5e cable
(maximum 100 m)
EIA/TIA-568 100 Ω STP
(maximum 100 m)
LEDs P
ower, Wireless 2.4 GHz, RS-485 (CH1–3)
Power adapter
rating
Input 100–240 VAC, 50–60 Hz
Output 12 VDC, 1 A
NaviLink power
rating
12 VDC, 0. 5 A
Safety &
Emissions
FCC, IC
