Navistar MaxxForce 9 Diagnostic Manual

DIAGNOSTICMANUAL
Step
ActionDecision
8
CheckforafailedAirManagementSystem(AMS)actuator.
1.UsingElectronicServiceT ool(EST)with
ServiceMaxx™software,gotoT ests>Load
TestSpecicSessionandverifyLoadT est
SpecicSessionisunchecked.
2.GotoSessions>Performanceandselectthe
recordsnapshoticonfromthetoolbar.
3.GotoTests>KOERTests>AirManagement
Test.
WhenAirManagementT estiscomplete,stoprecording.
UsetheplaybackfeatureinServiceMaxx™,andgraph
thefollowingsignalvalues:
SignalValues:
•EngineSpeed
•IntakeManifoldPressure(IMP)
•Turbocharger2WastegateControl(TC2WC)
DoessnapshotmatchGraph1orGraph2page120?
Graph1:Gotostep9A
Graph2:Diagnoseandrepairfailed
actuator(SeePerformanceDiagnostics
sectioninEngineDiagnosticManual).
Afterrepairsarecomplete,retestfor
originalproblem.
106
