Page #11 background image
REPEAT 3100 Installation and Operation Manual
NAVMAN
11
Physical
Case size 111 mm (4.4") square.
LCD display 82 mm (3.2") wide, 61 mm (2.4")
high; twisted nematic.
LCD digits 30 mm (1.2") high on top line,
20 mm (0.8") high on bottom line.
Four operator keys, laser etched.
Backlighting for display and keys, amber, four
levels and off.
Operating temperature 0 to 50°C (32 to 122°F).
Power cable length 1 m (3.25 ft).
Electrical
Power supply 10.5 to 16.5 V DC, 20 mA without
backlighting, 60 mA with full backlighting.
NavBus interface and display
NavBus interface for NAVMAN SPEED 3100,
DEPTH 3100, MULTI 3100 and/or WIND 3100
instruments.
Can receive and display these values from the
NavBus:
Current speed, average speed, maximum
speed, trim speed.
Log: trip log and total log.
Temperature.
Countdown timer (from SPEED 3100 or
MULTI 3100).
Depth.
Wind speed and direction (true and apparent).
VMG.
Appendix A - Specifications
NMEA interface and display
Three NMEA 0183 inputs for compatible NMEA
instruments.
Can receive and display these NMEA sentences:
APB, BEC, BOD, BWC, BWR, BWR, DBT,
DPT, GGA, GNS, HDG, HDT, HSC, MTW,
MWD, MWV, RMA, RMB, RMC, VDR, VHW,
VLW, VPW, VTG, WCV, XTE, XTR, ZDA (see
Appendix B).
Standards compliance
EMC compliance:
USA (FCC): Part 15 Class B.
Europe (CE): EN50081-1, EN50082-1.
New Zealand and Australia (C Tick):
AS-NZS 3548.
Environment: IP66 from front when correctly
mounted.
Power/data cable wires
Wire Signal
Red Power positive, 12 V DC
Black Power negative, NMEA common
Orange NavBus +
Blue NavBus -
White NMEA input 1
Yellow NMEA input 2
Green NMEA input 3
