AE- 1 5 0 s y s t e m – U s e r M a n u a l
34
Inhibition Channels Specifications
Number of Channels
2
Input range
-5V to +5V (TTL)
Comparison threshold
Selectable
Associated Logic
Acquisition Enable,
Acquisition Inhibit.
Pulse generator specifications
Amplitude (1MΩ)
16 V
Pulse Period
5 to 21 ms
Pulse Width
1 to 100 μs
Power supply specifications
Battery autonomy
More than 8 hours
DC-in Voltage
12V to 15V, 2.5A
Phase reference module
Power supply
110 VAC to 240 VAC
Frequency
50 Hz to 60 Hz
Wireless range
30 m
Wireless communication module
Wireless range
100 m in line of sight
Computer requirements
Minimal requirements
 Operating system: Windows XP, Vista, 7, 8 or 10
 RAM memory: 2GB and more
 Screen Resolution : 1280 by 800 pixels minimum
 One USB or serial port.
 Microsoft Word 2007 or later for report generation
