Technical specifications
Note: Specifications can change without notice.
Dimensions & Weight
Dimensions
396 x 371 x 140 mm (15.6 x 14.6 x 5.5 inches)
396 x 442 x 140 mm (15.6 x 17.4 x 5.5 inches)
(with antennas)
Weight
5.4 kg (12 lbs)
Acoustic channels
Number of Channels
4
Bandwidth
35 kHz to 300 kHz
Sampling Frequency
3 MHz (333 ns)
Optional Filtering
Highpass 6
th
order at 100 kHz
Amplitude Resolution
12 bits
Dynamic Range
120 dB
Input Range
500 mVpp max
Drive (for integrated pre-amplification)
0V, 5V (30 mA)
Sensitivity
6 µV
Partial Discharge channel
Number of Channels
1
Bandwidth
5 MHz to 300 MHz
Sampling Frequency
48 MHz
Input Range
1 Vrms
Sensitivity
100 µVrms
Dynamic Range
80 dB
Phase reference input Specifications
Number of channels
1
Bandwidth
50 Hz to 400 Hz
Input absolute maximum
± 24V peak
Supported waveforms
TTL, Sine, Square wave
Minimum amplitude for phase
detection
30 mV peak
Duty cycle
10% to 90%
