Page #4 background imageLoading...
Page #4 background image
1.1 Main Functions
Automatic or manual management of one or two leisure batteries, even of
different technologies and amperage
Output dedicated to engine battery charging, when leisure batteries are at 100%
(example: storage)
Displaying of the accumulators’ state of charge
Displaying of the charge and discharge voltage and ampere
Automatic (under 11V) or manual battery isolator, using the touch screen
Displaying of info and advices on managing and maintaining the batteries
Date and time
Temperature control under charge/discharge, for higher safety
2. INSIDE THE BOX
Make sure the box includes the following components:
'BlackBox' control device
'iManager' displaying device
'iManager' supply cable
No. 2 temperature probes
Assembling screw kit
Gli elementi forniti sono progettati esclusivamente per questo dispositivo e non
sono compatibili con altri dispositivi.
24
9.TECHNICAL DATA
BLACKBOX
Working voltage 12V (10V - 16V)
Relays maximum current 100A + 100A
Batteries’ automatic disconnection
threshold
Tensione: 10,5V
Temperatura: 60°C
Operation mode Automatico e Manuale
Maximum current on the Starter battery 4A (max 18A per 5sec dopo avvio carica)
Starter battery’s charging threshold < 12,5V Automatico ; < 12,7V Manuale
BlackBox average consumption 23mA@Batterie attive 4.2mA@Batterie OFF
Working temperature -15°C - +65°C
REMOTE DISPLAY
Type of Display TFT 2,83" 262k Colori con Touch Screen
Average Consumption
88mA@luminosità max. 24mA@Display OFF
0mA@batterie OFF alim. positivo comune
Type of Communication Wireless GFSK 868MHz
Operating temperature -10°C - +70°C
