8.3 NDS Useful Numbers:

Should you need to contact the NDS ENERGY S.r.l. technical department, by

pressing and holding the company logo on the upper left corner of the display, all the

company’s data are shown, including phone number and e-mail address for quick

use.

To exit that screen, just tap the display.

8.4 Current Reset and Measuring Errors

In case the system show you a residual current

different from Zero, when all loads and chargers

are switched off, if ppossible to do a Current Reset

and is possible to calibrate the battery Voltage

measures.

To do it:

 Open tha wondow that show the battery

Voltage and Current clicking on the area of

one of the leisure batteries;

 Click and hold for at least 10 seconds inside the area of the data showing

window

At this point the display show you the following screen:

At the rigth-top edge is showed the current

value of current and can be resetted clicking

on the Icon Reset I, while clicking on the + or

– icons you can calibrate the Voltage measure

for each Battery.

2.1 Device Components

››BLACKBOX

Front View: Back View:

NUMBER FUNCTION

2-way connector for connecting the Ground and the positive pole of the

Starter battery

2 M6 bolt connector for the Positive Pole of Leisure battery no. 1

3 M6 bolt connector for the system’s Common Positive Pole

4 M6 bolt connector for the Positive Pole of Leisure battery no. 2

5 4-way connector for the Cable of connection with iManager

6 Push Button for reactivating from Battery switch-off mode.

NDS iMANAGER User Manual
