NEC AccuSync LCD71VM User Manual

REPLACEMENT PARTS LIST
(For Europe)
The com
p
onents s
p
ecified for Model LCD71VM-BK
(
B
)
SYMBOL
Part No for NPG
DESCRIPTION
*** ICS ***
U401 EHA50051 IC SMD 24LC02B
U402 EHA50011 IC MOS 74LVC14
U404 EHA10511 IC SMD FAN1537PA REGULATO
U405 EHA10462 IC SMD GM2121 SCALER
U406 EHA10471 IC SMD MIC1815 RESET
U407 EHA10621 IC PLCC32 AT49F001NT MEMO
U408 EHA10081 IC SMD 24LC16B SO8
U409 EQ500117 CHIP FET P HAT1053M
U501 EH110241 IC LM4838MTEX AUDIO AMPLI
*** TRANSISTORS ***
Q401 EN000413 CHIP TR NPN 2SC2412K-T146
Q404 EN000413 CHIP TR NPN 2SC2412K-T146
Q405 EN000413 CHIP TR NPN 2SC2412K-T146
Q406 EN000413 CHIP TR NPN 2SC2412K-T146
Q407 EN000413 CHIP TR NPN 2SC2412K-T146
*** DIODES ***
D401 EX700216 DIODE RB495D
D402 EX500216 CHIP DIODE DAN217 T146
D403 EX500216 CHIP DIODE DAN217 T146
D404 EX500216 CHIP DIODE DAN217 T146
D801 EL200110 DIODE LED SML19460C
ZD401 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD402 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD405 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD406 EYD40562 CHIP DIODE ZENER UDZS5.6B
*** RELAYS & SWITCHES ***
SW801 JC300111 SW-TACT SKQNAED010
SW802 JC300111 SW-TACT SKQNAED010
SW803 JC300111 SW-TACT SKQNAED010
SW804 JC300111 SW-TACT SKQNAED010
SW805 JC300111 SW-TACT SKQNAED010
*** PWB ASSYS ***
MAININ
A
M0R61ML MAIN INSERT ASSY
POWERB JM100041 POWER B/D (17LG)"
SWINAS
A
S0R51ML SW INSERT ASSY
8-13
