5-2
1. General Description
Product Specifications
LG-Philips LM170E01-A4
Pixel Pitch 0.264mm
Resolution 1280x1024 pixels (SXGA)
Color 16.19 million color (R, G, B: 6bit + FRC)
Brightness 250cd/m
2
(Typical)
Contrast Ratio 450:1 (Typical)
LCD Module
Viewing Angle
70/70(L/R), 60/60(U/D) (CR>=10: Typical)
60/60(L/R), 50/45(U/D) (CR>=10: Minimum)
80/80(L/R), 70/70(U/D) (CR>=5: Typical)
70/70(L/R), 60/55(U/D) (CR>=5: Minimum)
Horizontal 31.5 – 81.1kHz
Frequency
Vertical 56.2 – 75.1Hz
Pixel Clock
25.1 – 135.0MHz
Viewable Size
337.92 x 270.336mm
Multi Pixel
Yes (with smoothing)
Digital Control
Yes
Color Control
Yes (3 preset memory + 1 user color)
On Screen Display
Yes
Power Management
Yes (VESA DPMS)
Plug and Play
Yes (VESA DDC2B/2Bi)
USB Hub
No
Speaker
Yes
Headphone Jack
Yes
Microphone Jack
No
Auto Adjustment
Yes (Position / Size / Phase)
Brightness control range
30% - 100% *
Controllable Function
Analog
Volume, Mute, Brightness, Contrast, Auto-Contrast,
Auto-Adjust, H. Posi, V. posi, H. Size, Fine, Color
Control, Language, OSM Turn Off, OSM Lock Out,
Resolution Nortifier, Monitor Info., Factory Reset
Signal Drive Separated Direct Drive
Video
RGB 0.7Vp-p
Input Impedance 75 ohm
Sync Separate sync: TTL Level (Positive / Negative)
Input Mini D-sub 15pin
DDC DDC2B
Input Signal (analog)
Signal Cable Mini D-sub 15pin Signal Cable (L=1.8m)
*: When user setting is minimum,
30% = (Brightness value [cd/m
2
] when user controls Brightness Max) x 0.3
