3-3
SYMBOL Part No for NPG DESCRIPTION
6 14000391 SC,CBIPS*3*10*15B
7 AS0R51ML SW INSERT ASSY
8 JN100021 SPEAKER ASSY
SYMBOL Part No for NPG DESCRIPTION CABINET COLOR Ver
9 10103811 BEZEL,L172R6-WH-NSP-ASSY White A ver
9 10103831 BEZEL,L172R6-BK-NSP-ASSY Black A ver
9 10103851 BEZEL,L172R6-BK(B)-NSP-AS Silver/Black B ver
10 11301621 KNOB CONTROL,L172R6-WH White A ver
10 11301631 KNOB CONTROL,L172R6-BK Black A ver
10 11301831 KNOB CONTROL,L172R6-SL Silver/Black B ver
6
7
8
S801
9
10
