5-9
Note 5. Distance between bright dots
Note 6. Distance between the group of (6)'s.
Note 7. Two or more pixels or sub-pixels with more than one fault of 5) within 5x5 pixels
Note 8. Two or more pixels or sub-pixels with more than one fault of 1) or 2) within 5x5 pixels
R R G G B B R R G G B B R G G B B R
Distance between the same color
Combination with Bright Dot & Dark
Dot
≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm ≤ 6.5mm
Count as defect Do not count as defect
R R R R G G G G B B B B
≤ 6.5mm ≤ 6.5mm ≤ 6.5mm
