Connect the Telephones
Quick Install Guide – SL2100 Terminals Type B rev 1.0 10
Cable LPNEC2 – 2m length, converts a two port RJ45 socket to two RJ45 plugs, one port per plug.
Can be used to connect into an RJ45 through coupler panel or directly into the customer’s
panels.
Can also be used to plug into RJ45 face plates if IDC termination is required.
Cable colour: black
One cable is required for the SLI socket of the IP7WW-082U-B1 card.
Adapter ADNEC14 – Converts a four port RJ45 socket to four RJ45 sockets, one port per socket.
Requires five patch cables of the desired length and colour.
Can be used to connect into an RJ45 through coupler panel or directly into the customer’s panels.
Can also be used to plug into RJ45 face plates if IDC termination is required.
Colour: black
Supplied with an adhesive pad.
One adapter is required for each ESI and SLI socket of the IP7WW-082U-B1 card.
