Using Cable Clamper
Tie the cables together using the cable clamper�
Preparing Your LCD TV For Wall Mounting (optional)
We suggest that you keep your TV at least 2�36 inches (60 mm) from the wall
to prevent cable interference� Before mounting your TV on the wall, you need
to remove the base� For your safety, only mount with a UL listed wall mount
bracket that supports the weight of the TV�(Please see page 36 and
page 39 )
To attach a wall mount bracket to your TV:
E654
step 1 step 2
Neck Screw
VESA Hole
1� Loosen the screws at the bottom of the base, and remove the base�
2� Loosen the screws at the bottom of the stand to remove the stand�
3� Secure the wall mount bracket to the back of your TV using four M6
screws�
screen size (inches) required pitch (mm) VESA Hole depth
65 400
×
400 4
×
M6 (30mm)
CAUTION: If you skip the step 1 and loosen the screws for stand directly,
please be sure to hold the base tightly to avoid dropping the base�
To Next Page
