English-38
Model Name E464 E424 E324
DISPLAY
Viewable 46” 42” 32”
Resolution 1,920
×
1,080 1,366
×
768
Color Over 16 million colors (depending on video card used)
Frequency
Horizontal:
31 ─ 83 KHz (Analog input)
15�625/15�734KHz, 31 - 83KHz
(HDMI input)
Vertical:
60 ─ 75 Hz (Analog input)
24Hz, 30Hz, 50Hz, 60Hz - 75Hz
(HDMI input)
Pixel Clock 25 ─ 156 MHz
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mild band (A - 8 through A - 1, A through I),
Super band (J through W),
Hyper band (AA through ZZ, AAA, BBB),
Ultra band (65 through 94, 100 through 125)
CONNECTIONS (Downward)
HDMI 2 / 3 Type A Connectors
PC IN
VGA Analog RGB (D-sub15 pin)
AUDIO Stereo mini jack
COMPONENT
/ AV IN
AV
(shared with
component
Y)
RCA PIN Type
1�0 V[p-p] / 75 ohm
AUDIO L / R
RCA PIN Type
0�5Vrms
Y
Pb/Cb, Pr/Cr
Y: 1�0 V [p-p]
Pb/Cb, Pr/Cr: 0�7V p-p 75 ohm
CONNECTIONS (Side)
RS-232C 9 Pin D-sub
USB USB2�0 DC 5V, Max� 500mA
HDMI 1 Type A Connectors
ANT / CABLE VHF / UHF
SPDIF OUT PCM, Fibre optic
