2
1.3 General Specification
The table below shows the general specification for the Blade Assembly Unit.
Major
classification
Minor
classification
Standard (N8405-005F) Remarks
Power supply Single-phase, 2-pole plug with
earthing point (one for each
power supply unit)
Voltage 100/200Vac ±10%
Frequency 50±1 Hz or 60±1 Hz
Input power
Waveform
distortion
10%
The power supply unit can
accept 100 to 240 Vac.
However, the specification
for the unit is as shown at
left.
Input current
(Max.)
36 A
Apparent
power (Max.)
3600 VA
Active power
(Max.)
3564 W
Rush current TBD
Power
consumption
Power factor 95%
Temperature 10 to 35ºC Temperature
and humidity
Humidity 20 to 80% RH No condensation
Operating TBD Noise
Standby
