10 Express5800/320La System Release Notes
11. Tighten the knurled screw that fastens the locking handle to the PCI module.
12. Following instructions in Step 3 above, disconnect PCI module 2 from the
system backplane.
13. Power up the system.
14. Enable the greater than 4GB disc geometry in PCI module 1 as follows.
! As the system reboots, watch for the message “Press Alt Q to enter
“Qlogic Fast!UTIL.” When you see the message, press Alt Q. The Fast!
UTIL Options screen displays.
! Select Select Host Adapter and press ENTER. The Select Host
Adapter screen displays.
! Select QLA12160 Ultra 3 and press ENTER. The Fast!UTIL Options
screen displays.
! Select Configuration Settings and press ENTER. The Configuration
Settings screen displays.
! Select Host Adapter Settings and press ENTER.
! Select >4Gbyte Addressing and change the setting to Enabled.
! Press Esc until the “Configuration settings modified” box displays.
Select Save Changes and press Enter. Press Esc and the Exit
Fast!UTIL box is displayed.
15. Power down the system.
16. Following instructions in Steps 8 through 11 above, install PCI module 2
into the system.
17. Power on the system. 4GB disc geometry is configured in each PCI module.

NEC Express5800 320La Specifications

General

Form Factor	Tower
CPU	Intel Xeon Processor
Storage	SCSI/SATA
Network	Integrated Ethernet
Operating System Support	Windows Server, Linux
Expansion Slots	6 total: 2 x 64-bit PCI, 2 x 32-bit PCI, 1 x shared PCI/ISA, 1 x ISA
