INTRODUCTION
2
SPECIFICATIONS
24CG
ITEM
ITK-24CG-1/ ITK-24CG-1A / ITK-24CG-1P / ITK-24CG-1U
LCD
4.3 inch TFT, with back light
LCD color
Color (16,194,277 colors)
Programmable
line/feature key
24 keys
Fixed feature key
13 keys (with Menu key and Cursor key)
Soft key
4 keys
Back light
LCD and digit key (lit for 10 seconds when operating)
Phonebook
(Terminal)
1,000 records per terminal
Phonebook
(System)
System : Max 30,000 records per
system
Personal : Max 1,000 records per terminal
Call history
(System)
Outgoing Call: Max 60 records per terminal
Incoming Call: Max 60 records per terminal
XML browser
Available
Handsfree
Available (Full duplex), Wideband support
Headset
Available (HW510 (A10) / HW251N (A10) / WT100 (APN-91)
/
Voyager Legend CS
(APN-91) / W710(APD-80) / W710(APN-91)
Speaker
-
LAN interface
2-port, 10BASE-T/100BASE-TX/1000BASE-T, Full-duplex/Half-duplex, Auto
Negotiation/Fixed (Except 1000BASE-T)
Voice CODEC
G.711 (μ-law, A-law), G.729a, G.722
IP address setting
Sets via DHCP server/Sets Statically
QoS
ToS (IP PrecedenceDiffserv)
VLAN
Tag VLAN (IEEE802.1Q/p)LLDP-MEDDHCP
Security
IEEE802.1x authentication (EAP-MD5, EAP-TLS), IEEE802.1x authentication
support (EAPoL Forwarding) on the PC port via switch at a high hierarchy level,
SIP&RTP Encryption, HTTPS (Web Programming/Download), VPN (L2TP/IPsec
(IPv4))
Power supply
Central Power Supply = IEEE802.3at Type1 (IEEE802.3af compatible)
Local Power Supply = AC adapter (Option)
Power
consumption
Max : About 4.2W Standby : About 2.2W
(without optional connection)
Download
Boot & Program / Config /Ringing Tone / Music on Hold/ Phonebook / Phonebook list
/ Wallpaper / Voice confirmation tone
Adapter and
Accessory
(Option)
Ancillary Device Adapter (ADA) Wall Mount unit (WM) / Line Key Unit (8LK) /
Directory Card /60 button DSS/ Numbered Keypad
Dimension (W×D
×H)
About 181(W) × About 254(D) × About 152(H)
Weight
About
1.0Kg
Environmental
Temperature range = 0 to 40 (Ambient temperature range = -20 to 60 )
Humidity = 10 to 90% RH (non condensing)
