The supplied parts are as follows.
I n case one of these parts is m issing or dam aged, contact the ret ailer.
Parts Specications
Quant it y
LED-E012i-108 LED-E015i-135 LED-E018i-162 LED-E012i-217 LED-E025i-217
Bot t om fram e 1 1 1 2
Bot t om fram e
connect ing part
- - - 1
Bot t om fram e
connect ing screw
PM3 - - - 8
KM3 - - - 8
Mount ing bar 2 2 3 4
Alignm ent bar 2 2 2 2
Cabinet hanger pin Head diam eter
10 m m x 25 m m
16 20 36 64
Bot t om fram e
screw
M6 x 16 6 6 9 12
Over fram e ( t op) 1 1 1 1
Over fram e ( left ,
right )
2 2 2 2
Corner fram e 2 2 2 2
Slot nut M3 x 13 m m 12 15 18 24
Screw for the slot
nut
M3 x 10 m m 12 15 18 24
