DVD player
Connecting Your DVD Player
Audio Equipment
Optional 15-pin-to-RCA
(female)⳯3 cable (ADP-CV1)
Audio cable (not supplied)
You can connect your projector to a DVD player with component output or
Video output. To do so, simply:
1. Turn off the power to your projector and DVD player.
2. If your DVD player has the component video (Y,Cb,Cr) output, use a com-
mercially available component video cable (RCA⳯3) and the optional
15-pin-to-RCA (female)⳯3 cable to connect your DVD player to the RGB
IN1 or IN2 connector on the projector.
For a DVD player without component video (Y,Cb,Cr) output, use com-
mon RCA cables (not provided) to connect a composite VIDEO output of
the DVD player to the Video Input of the projector.
3. Turn on the projector and DVD player.
NOTE: Refer to your DVD player's owner's manual for more information about
your DVD player's video output requirements,
Component video
RCA⳯3 cable
(not supplied)
