143
8. Appendix
368 (14.5)
286(11.3)
134 (5.3)
130 (5.2)
150 (5.9)
200 (7.9)
175 (6.9)
98 (3.9)
80 (3.2)
108 (4.3)
291 (11.5)
[M352WS/M302WS/M332XS]
Lens center
Lens center
Holes for ceiling mount
Unit:mm(inch)
