2. Projecting an Image (Basic Operation)
❺ Adjusting the Picture Size and Position
Usetheadjustabletiltfoot,thezoomfunctionorthefocusringtoadjustthepicturesizeandposition.
Inthischapterdrawingsandcablesareomittedforclarity.
Adjustingthethrowangle(theheightofanimage)
[Tiltfoot](→page21)
Adjustingtheleftandrighttiltofanimage
[Rearfoot](→page21)
Finelyadjustingthesizeofanimage
[Zoomfunction](→page22)
Adjustingthefocus
[Focusfunction](→page23)
Adjustingthekeystonecorrection[KEYSTONE]*(→page24)
* AutomaticKeystoneCorrectionfunctionisturnedonatthetimeofshipment.Toperformkeystonecorrectionmanually,see“6.
CorrectingKeystoneDistortionManually”onpage24.
