1. Introduction
❸ Part Names of the Projector
Front/Top
[M402W/M362W/M322W/M402X/M362X/M322X/M282X]
Controls
(→ page 8)
Remote Sensor
(→ page 11)
Exhaust Vent
Heated air is exhausted from here.
Port Cover for Optional USB
Wireless LAN Unit
When using the optional USB
Wireless LAN Unit, first remove
the cover. (→ page 129)
Zoom Lever (→ page 22)
Lens Cover
Focus Ring
(→ page 23)
Adjustable Tilt Foot Lever
(→ page 21)
Adjustable Tilt Foot
(→ page 21)
Lens
Light Sensor
(→ page 95)
Security chain opening
Attach an anti-theft device.
The security chain opening accepts
security wires or chains up to 0.18
inch/4.6 mm in diameter.
Opening and closing the lens cover
Slidethelenscovertotherighttouncoverthelens.
Tocoverthelens,slidethelenscovertotheleft.
NOTE:
• ThelenscoverworksinconjunctionwiththeAV-MUTEfunction.Closingthelenscoverwillturnofftheimageandsoundduring
normalprojectoroperation;openingitwillrestoretheimageandsound.
 Withthelenscoverclosedtheimageandsoundisturnedoff,howeverthelampisstilllit.Iftheprojectorstaysthiswayforabout
2hours,itwillturnoffautomatically.
• Donotpullthelenscoverwithexcessiveforceorapplystrongpressureineithertheupordowndirection.Doingsocancause
damagetothelenscoverslidingmechanism!
