NEC MultiSync LCD1550ME User Manual

REPLACEMENT PARTS LIST
The com
p
onents s
p
ecified for Model LCD1550ME
(
B
)
SYMBOL PART NO DESCRIPTION
*** ICS ***
I001 79PL1440 IC TDA7496L 20P PDIP SG
I301 79PL1948 IC-M51953AFP-8P-SOP
I302 79PL1951 IC-MTV312MV64-44P-PLCC-MY
I303 79PL1950 IC-TTL-NC7SZ04M5X-5P-FAIR
I304 79PL1447 IC 24LC32A 8P SOP MICROCH
I305 79PL1949 IC-TTL-NC7SZ08M5X-5P-FAIR
I306 79PL1323 IC GMZAN1 160P PQFP GENES
I308 79PL2046 IC-CPU-24LC024-8PIN-SOIC-
I309 79PL1322 IC LM358DT 8P SOP ST
I310 79PL1441 IC AIC1084 33CM 3P TO26
I801 79PL1439 IC KA3842AE S 8P PDIP F
I802 79PL1438 IC LTV 817D 4P PDIP LIT
I803 79PL1437 IC KA431AZ 3PIN TO-92 T
*** TRANSISTORS ***
Q301 79PL1321 TR NPN SST2222A 800MA/50V
Q302 79PL1321 TR NPN SST2222A 800MA/50V
Q303 79PL1435 FET P-CHNL SI2305DS VISHA
Q304 79PL1036 TR NPN SST3904 SMD
Q305 79PL1037 TR PNP 2SA1037AK T146/R
Q306 79PL1036 TR NPN SST3904 SMD
Q307 79PL1036 TR NPN SST3904 SMD
Q308 79PL1436 FET N&P-CHNL 2SK3018 ROHM
Q309 79PL1436 FET N&P-CHNL 2SK3018 ROHM
Q310 79PL1037 TR PNP 2SA1037AK T146/R
Q311 79PL1036 TR NPN SST3904 SMD
Q312 79PL1436 FET N&P-CHNL 2SK3018 ROHM
Q313 79PL1436 FET N&P-CHNL 2SK3018 ROHM
Q803 79PL2058 FET-N-CHNL-SSS4N60AS-2.3A
Q806 79PL2069 TRANSISTOR-PNP-2SA733P-T-
*** DIODES ***
D301 79PL1947 DIODE-MM4148-SMD-GOODARK
D304 79PL1947 DIODE-MM4148-SMD-GOODARK
D305 79PL1144 DIODE ZNR RLZ TE-11 5.6B
D306 79PL1947 DIODE-MM4148-SMD-GOODARK
D307 79PL1144 DIODE ZNR RLZ TE-11 5.6B
D308 79PL1947 DIODE-MM4148-SMD-GOODARK
D309 79PL1144 DIODE ZNR RLZ TE-11 5.6B
D310 79PL1249 DIODE DAN217 T146 SMD3
D311 79PL1249 DIODE DAN217 T146 SMD3
8-1
