7-5
(2) Out of range
This out-of-range mode is assumed when the frequency of the horizontal / vertical signal is as specified
below.
Vertical frequency : Below 56.2Hz or above 75.1Hz
Horizontal frequency : Below 31.5KHz or above 60KHz
(3) Power save mode.
The power save mode is assumed when the horizontal / vertical signals are as specified below.
If there is no horizontal sync signal input.
If there is no vertical sync signal input.
If the horizontal sync signal outside the measuring range of gmZAN1.
If the vertical sync signal outside the measuring range of gmZAN1.
Table 1
Polarity
Mode No Resolution
H-freq
(KHz)
Band Width
(MHz)
H V
1. 247 VGA 720 x 350 70Hz 31.47 28.322 + -
2. 102 VGA 720 x 400 70Hz 31.47 28.322 - +
3. 103 VGA 640 x 480 60Hz 31.47 25.175 - -
4. 182 MAC 640 x 480 66Hz 35 30.24 - -
5. 173 VESA 640 x 480 72Hz 37.86 31.5 - -
6. 109 VESA 640 x 480 75Hz 37.5 31.5 - -
7. 104 VESA 800 x 600 56Hz 35.16 36 + +
8. 116 VESA 800 x 600 60Hz 37.88 40 + +
9. 110 VESA 800 x 600 75Hz 46.88 49.5 + +
10. 117 VESA 800 x 600 72Hz 48.08 50 + +
11. 108 MAC 832 x 624 75Hz 49.72 57.283 - -
12. 118 VESA 1024 x 768 60Hz 48.36 65 - -
13. 217 SUN 1024 x 768 65Hz 52.45 70.49 - -
14. 157 VESA 1024 x 768 70Hz 56.48 75 - -
15. 141 VESA 1024 x 768 75Hz 60.02 78.75 + +
Attention:
1. When resolution beyond 1024 x 768 is inputted, resolution is lowered with Down scaling to
1024 x 768, and indicated, and OSD should indicate OUT of Range.
