5-3
Power Supply
Universal AC100 – 240V
Current Rating
1.2A (AC100V) / 0.6A (AC240V)
Temp.
5 – 35°C
Operational Environment
Humid. 30 – 80% (without condensation)
Net 367.0(W) x 362.0 – 472.0(H) x 198(D) mm
Dimension
Gross 426.0(W) x 446.0(H) x 252.0(D) mm
Net 7.5kg
Weight
Gross 9.8kg
VESA compatible arm mounting interface
Yes, 100mm x 100mm
Tilt / Swivel / Rotation
Up & Down 30° to -5° / Yes ±170° / NA
Complied Regulatory and Guidelines
Safety: UL / c-UL, TuV GS
EMC: FCC-B
VLF / ELF: MPR-II, TCO’03
Others: CE, Ctick, PSB, AS, TCO’03(AN),
TCO’99(ANBK), GOST, PCBC, BSMI
Accessories
User’s manual, AC Power code (2.0m), Analog Cable
(2.0m, mind-sub 15 pin), Digital Cable (2.0m, DVI-D),
USB Cable (2.0m)
2. Electrical Characteristics
2.1 Power Supply
Input Voltage (Rating) 100 – 240VAC
Input Voltage Range 90 – 264VAC
Frequency (Rating) 50 / 60Hz
Frequency Range 47 – 63Hz
Power Consumption 38W (Typ.)
AC Leakage Current < 0.25 mA @AC 100V, < 3.5mA @AC230V
Inrush Current (Cold Start) < 30A
0-P
@AC110V, < 50A
0-P
@AC220V
AC Input
KK+Inlet connector type
3 polarity, 10A 250V 65°C
VDE, UL CSA approved CEE input connector.
EN60320 Class I standard compliant
Pin Name I/O Definition
1 L I Live
2 N I Neutral
3 FG I Frame GND
