5.5 EDID Data File
EDID date: LCD1970NX_A.edi (ANALOG)
0 1 2 3 4 5 6 7 8 9 A B C D E F
00
00 FF FF FF FF FF FF 00 38 A3 62 66 01 01 01 01
10
Note1 Note2
01 03 0E 26 1E 78 EA CB 05 A3 58 4C 9B 25
20
13 50 54 BF EF 80 71 4F 81 40 81 80 01 01 01 01
30
01 01 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70
40
13 00 78 2D 11 00 00 1E 00 00 00 FD 00 38 4B 1F
50
51 0E 00 0A 20 20 20 20 20 20 00 00 00 FC 00 4C
60
43 44 31 39 37 30 4E 58 0A 20 20 20 00 00 00 FF
70
00
Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3
00
Note4
EDID date: LCD1970NX_D.edi (DIGITAL)
0 1 2 3 4 5 6 7 8 9 A B C D E F
00
00 FF FF FF FF FF FF 00 38 A3 62 66 01 01 01 01
10
Note1 Note2
01 03 80 26 1E 78 EA CB 05 A3 58 4C 9B 25
20
13 50 54 BF EF 80 71 4F 81 40 81 80 01 01 01 01
30
01 01 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70
40
13 00 78 2D 11 00 00 1E 00 00 00 FD 00 38 4B 1F
50
51 0E 00 0A 20 20 20 20 20 20 00 00 00 FC 00 4C
60
43 44 31 39 37 30 4E 58 0A 20 20 20 00 00 00 FF
70
00
Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3 Note3
00
Note4
Note 1: address 10h Week of manufacture = Month of manufacture × 4
Note 2: address 11h Year of manufacture - 1990
Note 3: address 71h ~ 7Dh Serial Number (ASCII coded)
If less than 13 char, terminate with 0Ah and fill the rests with 20h.
Note 4: address 7Fh Checksum
The sum of entire 128 byte should be equal to 00h.
