5-24
MODE
No. 19
Item Abbreviation VESA 1280x1024 75Hz
Pixel frequency fc 135.00MHz
Horizontal frequency fh 79.98kHz
Line Time total Th 12.50us 1688CLK
Horizontal active display Thd 9.48us 1280CLK
Horizontal sync pulse Thp 1.07us 144CLK
Horizontal back porch Thb 1.84us 248CLK
Horizontal front porch Thf 0.12us 16CLK
Horizontal sync polarity POS
Vertical Frequency fv 75.03Hz
Frame time total Tv 13.33ms 1066H
Vertical active display Tvd 12.80ms 1024H
Vertical sync pulse Tvp 0.04ms 3H
Vertical back porch Tvb 0.48us 38H
Vertical front porch Tvf 0.01ms 1H
Vertical sync polarity POS
