7-2
1. Block Diagram
S401 to Panel
S402
to
Powe B/D
U403
Scaler
Gm5221
U408 24LC16
P401 DVI
S404 to Key B/D
S403 to G-probe
U406 24LC02
U407 24LC02
U405 ROM A29002
U402 SW
HAT1053
X401 14.3MHz
LVDS
+12V
+5V
3.3V
1.8V
DDC Data
DDC Data
Mute
Inverter control
U409 74LVC14
R,G,BR,G,B
HV
P402 DSUB
U401 MW1537
